Cisco 5596UP
48 x RJ45, unified, 2 RU, 32,000 MAC address, 4096 VLANs, IGMP, QoS, 390W, 2 x 1100W AC Power Supplies, Fan Trays, 3 Expansion Slot, 21.55 kg
The Cisco Nexus 5500 platform is equipped with expansion modules that can be used to increase the number of 10 Gigabit Ethernet and FCoE ports or to connect to Fibre Channel SANs with 8/4/2/1-Gbps Fibre Channel switch ports, or both.
The Cisco Nexus 5548P and 5548UP supports one expansion module, and 5596UP supports three expansion modules from the following offerings
- Ethernet module that provides sixteen 1/10 Gigabit Ethernet and FCoE ports using the SFP+ interface
- Fibre Channel plus Ethernet module that provides eight 1/10 Gigabit Ethernet and FCoE ports using the SFP+ interface, and eight ports of 8/4/2/1-Gbps native Fibre Channel connectivity using the SFP+/SFP interface
- A unified port module that provides up to sixteen 1/10 Gigabit Ethernet and FCoE ports using the SFP+ interface or up to sixteen ports of 8/4/2/1-Gbps native Fibre Channel connectivity using the SFP+ and SFP interface. The use of 1/10 Gigabit Ethernet or 8/4/2/1-Gbps Fibre Channel on a port is mutually exclusive but selectable for any of the 16 physical ports per module.
The Cisco Nexus 5548P and 5548UP supports one expansion module, and 5596UP supports three expansion modules from the following offerings
- Ethernet module that provides sixteen 1/10 Gigabit Ethernet and FCoE ports using the SFP+ interface
- Fibre Channel plus Ethernet module that provides eight 1/10 Gigabit Ethernet and FCoE ports using the SFP+ interface, and eight ports of 8/4/2/1-Gbps native Fibre Channel connectivity using the SFP+/SFP interface
- A unified port module that provides up to sixteen 1/10 Gigabit Ethernet and FCoE ports using the SFP+ interface or up to sixteen ports of 8/4/2/1-Gbps native Fibre Channel connectivity using the SFP+ and SFP interface. The use of 1/10 Gigabit Ethernet or 8/4/2/1-Gbps Fibre Channel on a port is mutually exclusive but selectable for any of the 16 physical ports per module.
Data sheet
- 10G support
- Yes
- AC input frequency
- 50/60 Hz
- AC input voltage
- 100-240 V
- Basic switching RJ-45 Ethernet ports quantity
- 48
- Basic switching RJ-45 Ethernet ports type
- 10G Ethernet (100/1000/10000)
- Certification
- RoHS
- Colour of product
- Silver
- Copper ethernet cabling technology
- 1000BASE-TX,100BASE-TX,10BASE-T
- Depth
- 749 mm
- DHCP client
- Yes
- DHCP server
- Yes
- Dimensions (WxDxH)
- 439 x 749 x 88 mm
- Electromagnetic compatibility
- 47CFR, AS/NZS CISPR22, CISPR22, EN55022, ICES003, VCCI
- Ethernet LAN (RJ-45) ports quantity
- 1
- Heat dissipation
- 1331 BTU/h
- Height
- 990mm
- Input voltage
- –36 - –72 V
- MAC address table
- 96000 entries
- Management protocols
- SSHv2, Telnet, RADIUS, TACACS+, SNMP, RMON, RBAC, NTP
- Maximum data transfer rate
- 1920 Gbit/s
- Networking standards
- IEEE 802.1D,IEEE 802.1Q,IEEE 802.1Qaz,IEEE 802.1Qbb,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.3,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3u,IEEE 802.3x
- Non-operating altitude
- 0 - 300 m
- Operating altitude
- 914.4 - 2133 m
- Operating relative humidity (H-H)
- 5 - 95 %
- Operating relative humidity range
- 0 - 40 %
- Operating temperature (T-T)
- 8 - 35 °C
- Ports quantity
- 48
- Power consumption (typical)
- 680 W
- Safety
- UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, AS/NZS 609, GB49430-1
- Security algorithms
- 802.1x RADIUS,AES
- Source data-sheet
- Icecat.biz
- Stackable
- No
- Storage relative humidity range
- 5 - 95 %
- Storage temperature (T-T)
- 8 - 85 °C
- Storage temperature range (T-T)
- -40 - 70 °C
- Switch layer
- L7
- Switching protocols
- EIGRP, OSPFv2, BGP, HSRP, VRRP, PIMv2, MSDP, IGMPv2/v3
- Weight
- 21550 g
- Width
- 439 mm
Specific References
- EAN13
- 0882658390890
48 x RJ45, unified, 2 RU, 32,000 MAC address, 4096 VLANs, IGMP, QoS, 390W, 2 x 1100W AC Power Supplies, Fan Trays, 3 Expansion Slot, 21.55 kg
