D-Link DMC-300SC

D-Link DMC-300SC

100BASE-TX to 100BASE-FX Multimode SC Media Converter
Out of Stock
Reference: DMC-300SC/B

Require Project Pricing?

Click here to email your parts list and we will send you a quote
Designed to convert 10BASE-T/100BASE-TX copper to 100Base-FX fiber media and vice versa, the DMC-300SC offers conversion from fiber to copper to minimize cost and extend hauls.



The DMC-300SC by D-Link® is a media converter designed to connect 10BASE-T/100BASE-TX copper to 100Base-FX fiber media and vice versa. Based on the IEEE 802.3 and 802.3u standards, the DMC-300SC is designed for use with multimode fiber cable utilizing the SC-Type connector. The DMC-300SC supports shortwave (SX) laser specifications at a full wire-speed forwarding rate. Other features of this module include the ability to be used as a standalone device (no chassis required), Auto MDI/MDI-X, Auto negotiation of speeds and duplex modes on twisted-pair port, and front panel status LEDs. The DMC-300SC will transmit at extended

Data sheet

Cable type
UTP Cat. 3, 4, 5; 62.5/125μm MM Fiber; 10/125μm SM Fiber
Cabling technology
10Base-T, 100BASE-T, 100Base-FX
Certification
FCC Class B, VCCI Class B, CE Class B
Dimensions (WxDxH)
89 x 119 x 25 mm
Interface
RJ-45, SC
LED indicators
LAN
Operating relative humidity (H-H)
10 - 90 %
Operating relative humidity range
10 - 90 %
Operating temperature (T-T)
8 - 35 °C
Operating temperature range (T-T)
0 - 40 °C
Power consumption (typical)
7.2 W
Power requirements
7.5V, 1.5A
Source data-sheet
Icecat.biz
Storage temperature (T-T)
-25 - 70 °C
Storage temperature range (T-T)
-25 - 70 °C
Weight
VFD and cable: 36.6 lb; Pole (each): 50.7 oz; Base: 66.1 lb (VFD and cable: 1.29 lb; Pole (each): 1.79 oz; Base: 2.33 lb)

Specific References

EAN13
0790069241819
