HP 3800-24G-2XG

Hewlett Packard Enterprise 3800-24G-2XG

Managed, 24 x RJ-45 10/100/1000 Mbps, 2 x RJ-45 10-GbE, 1 x RJ-45 Console, HP ProVision ASIC/ARM 350 MHz, Freescale PowerPC 1200 MHz, 4GB Flash, Buffer 18 MB, 2GB SDRAM, RADIUS/TACACS+, SSHv2, SSL, 48.26 cm (19 ") , 127W, 7.17kg
Out of Stock
Reference: J9585A

Require Project Pricing?

Click here to email your parts list and we will send you a quote
The HP 3800 Switch Series is a family of fully managed Gigabit Ethernet switches. There are a total of nine switch models—a 24-port switch, a 48-port switch, a 24-port PoE+ switch, a 48-port PoE+ switch

with either SFP+ or 10GBASE-T uplinks, and a 24-portSFP switch with 2 SFP+ uplinks. HP 3800 Series Switches utilize the latest HP ProVision ASIC technology and combine the latest advances in hardware engineering to deliver one of the most resilient and energy-efficient switches in the industry.

The 3800 series implements meshed stacking technology to deliver chassis-like resiliency in a flexible stackable form factor.

Data sheet

10G support
Yes
Authentication method
IEEE 802.1X, RADIUS, MAC
Auto MDI/MDI-X
Yes
Basic switching RJ-45 Ethernet ports quantity
26
Built-in processor
HP ProVision ASIC/ARM 350 Mhz & Freescale PowerPC 1200 MHz
Certification
FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A
EN 55024, CISPR 24, EN 55024, CISPR 24, IEC 61000-4-2/3/4/5/6/8/11, IEC 61000-3-2/3, EN 61000-3-2/3
80 PLUS GOLD
Colour of product
Grey
Connectivity technology
Wired
Copper ethernet cabling technology
1000BASE-T,100BASE-TX,10BASE-T,10GBASE-T
DHCP client
Yes
DHCP server
Yes
Diagnostics
LLDP
Dimensions (WxDxH)
467.4 x 442.7 x 43.2 mm
Ethernet LAN (RJ-45) ports quantity
26
Flash memory
96 MB
Form factor
19"
Input current
6 - 3 A
Input voltage
–36 - –72 V
Installed ports
26
Internal memory
≈ 5,000 Cat 8 with plots; ≈ 12,000 Cat 6A with plots
Latency
1.9µs
MAC address table
65500 entries
Management platform
SNMP, Telnet, Web
Management protocols
SNMP v3
Maximum data transfer rate
10000 Gbit/s
Memory type
SDRAM
Networking features
Gigabit Ethernet, 10G Ethernet
Networking standards
IEEE 802.1ab,IEEE 802.1D,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u
Noise level
97.4 dB
Number of VLANs
2048
Operating altitude
914.4 - 2133 m
Operating relative humidity (H-H)
15 - 95 %
Operating relative humidity range
15 - 95 %
Operating temperature (T-T)
8 - 35 °C
Operating temperature range (T-T)
0 - 55 °C
Packet buffer memory
18 MB
Ports quantity
26
Power consumption (typical)
127 W
Power over Ethernet (PoE) support
No
Power supply
400 W
Power supply type
HP X311
Safety
EN 60950/IEC 60950, UL 60950, CAN/CSA 22.2 No. 60950, EN 60825
Security algorithms
802.1x RADIUS,SSH,SSL/TLS
Security algorithms supported
802.1x RADIUS, SSH, SSL/TLS
Security features
CLI, GUI, MIB
Source data-sheet
Icecat.biz
Storage relative humidity (H-H)
15 - 90 %
Storage temperature (T-T)
8 - 85 °C
Storage temperature range (T-T)
-40 - 70 °C
Supported data transfer rates
x1 115.2 Kbits/sec., x2 230.4 Kbits/sec., x4 460.9 Kbits/sec
Switch layer
L7
Switching capacity
88 Gbit/s
Throughput
65400000 pps Mpps
Weight
7170 g
Wireless LAN connection
No

Specific References

EAN13
0886112028336
