Hewlett Packard Enterprise X132 10G SFP+ LC LR
10G, 9/125 µm, SFP+, 10 km, 200g, Silver
A 10-Gigabit transceiver in SFP+ form-factor that supports the 10-Gigabit LR standard, providing 10-Gigabit connectivity up to 10 km on single-mode fiber.
Data sheet
- Auto MDI/MDI-X
- No
- Cable type
- Single-mode
- Connectivity technology
- Wired
- Data transfer rate (max)
- 10000 Mbit/s
- Depth
- 13.7 mm
- Dimensions (WxDxH)
- 55.5 x 13 x 12 mm
- Fiber optic connector
- XFP
- Height
- 11.9 mm
- Interface
- 1 x 10GBase-LR
- Interface type
- SFP+
- Maximum transfer distance
- 900 m
- Networking standards
- Plug and Play, CE, FCC Class A certified, UL, TUV GS, VCCI, C-Tick, BSMI CNS 13438 Class A
- Operating altitude
- 914.4 - 2133 m
- Operating relative humidity (H-H)
- 0 - 85 %
- Operating temperature (T-T)
- 8 - 35 °C
- Operating temperature range (T-T)
- 0 - 70 °C
- Power consumption (typical)
- 1 W
- RoHS compliance
- No
- Source data-sheet
- Icecat.biz
- Storage temperature (T-T)
- 8 - 85 °C
- Storage temperature range (T-T)
- -40 - 85 °C
- Wavelength
- [1250 nm – 1600 nm]
- Weight
- 200 g
- Width
- 55.6 mm
Specific References
- EAN13
- 0884420143314
10G, 9/125 µm, SFP+, 10 km, 200g, Silver
