Hewlett Packard Enterprise 3600-48-PoE+ v2 EI
HP 3600-48-PoE+ v2 EI Switch
The HP 3600 EI Switch Series delivers resiliency, security, and reliability at the enterprise edge with support for advanced Layer 3 and multicast routing. This advanced Layer 3 Fast Ethernet switch series has a robust feature set supporting IRF stacking, Static & RIP Routing, OSPF, BGP, IS-IS, PoE+, ACLs, and IPv6.
The HP 3600 EI Switch Series can be managed with the optional HP Intelligent Management Center (IMC) Software Platform for a single view of your entire network and includes a Limited Lifetime Warranty 2.0 with 3 years 24x7 phones support.
Features
Resilient and Reliable Fast Ethernet Access Layer Switches
The HP 3600 EI Switch Series delivers resiliency, security, and reliability at the enterprise edge with support for advanced Layer 3 and multicast routing.
Designed for increased flexibility and scalability, the 3600 EI Switch Series come with 24- or 48- 10/100 ports and four SFP Gigabit Ethernet ports for stacking and uplinks, a 24-port 100BASE-FX switch with two or four Gigabit Ethernet SFP slots and models with 370W of PoE+ power.
The HP Intelligent Resilient Framework (IRF) virtualizes up to nine physical switches into one logical device for simpler, flatter, more agile networks.
Enterprise class features include Dynamic and Multicast Routing, RIP, OSPF, BGP, PIM and ECMP.
Limited Lifetime Warranty 2.0 with 3 years 24x7 phone support and no software licensing required.
Powerful Quality of Service (QoS)
The HP 3600 EI Switch Series supports advanced classifier-based QoS which classifies traffic using multiple match criteria based on Layer 2, 3, and 4 information; applies QoS policies such as setting priority level and rate limit to selected traffic on a per-port or per-VLAN basis.
Provides extensive traffic prioritization with congestion actions: strict priority (SP), weighted round robin (WRR), weighted fair queuing (WFQ), and weighted random early discard (WRED).
Integrated and Distributed Security Enforcement
The HP 3600 EI Switch Series supports flexible authentication methods including 802.1X, MAC, and Web Authentication for greater security and policy-driven application authentication.
Identity-driven security and access control with automatic VLAN assignment and per-user ACLs allows access to specific network services without risking network security.
Security features include: IP source guard, STP BPDU port protection, and RADIUS/HWTACACS.
Single View of the Network
The HP 3600 EI Switch Series can be seamlessly managed with the optional HP Intelligent Management Center (IMC) Software Platform to provide end-to-end network transparency with consistent network experience through comprehensive configuration, compliance and policy management.
RMON and sFlow provides advanced monitoring and reporting capabilities for statistics, history, alarms, and events.
The HP 3600 EI Switch Series can be managed with the optional HP Intelligent Management Center (IMC) Software Platform for a single view of your entire network and includes a Limited Lifetime Warranty 2.0 with 3 years 24x7 phones support.
Features
Resilient and Reliable Fast Ethernet Access Layer Switches
The HP 3600 EI Switch Series delivers resiliency, security, and reliability at the enterprise edge with support for advanced Layer 3 and multicast routing.
Designed for increased flexibility and scalability, the 3600 EI Switch Series come with 24- or 48- 10/100 ports and four SFP Gigabit Ethernet ports for stacking and uplinks, a 24-port 100BASE-FX switch with two or four Gigabit Ethernet SFP slots and models with 370W of PoE+ power.
The HP Intelligent Resilient Framework (IRF) virtualizes up to nine physical switches into one logical device for simpler, flatter, more agile networks.
Enterprise class features include Dynamic and Multicast Routing, RIP, OSPF, BGP, PIM and ECMP.
Limited Lifetime Warranty 2.0 with 3 years 24x7 phone support and no software licensing required.
Powerful Quality of Service (QoS)
The HP 3600 EI Switch Series supports advanced classifier-based QoS which classifies traffic using multiple match criteria based on Layer 2, 3, and 4 information; applies QoS policies such as setting priority level and rate limit to selected traffic on a per-port or per-VLAN basis.
Provides extensive traffic prioritization with congestion actions: strict priority (SP), weighted round robin (WRR), weighted fair queuing (WFQ), and weighted random early discard (WRED).
Integrated and Distributed Security Enforcement
The HP 3600 EI Switch Series supports flexible authentication methods including 802.1X, MAC, and Web Authentication for greater security and policy-driven application authentication.
Identity-driven security and access control with automatic VLAN assignment and per-user ACLs allows access to specific network services without risking network security.
Security features include: IP source guard, STP BPDU port protection, and RADIUS/HWTACACS.
Single View of the Network
The HP 3600 EI Switch Series can be seamlessly managed with the optional HP Intelligent Management Center (IMC) Software Platform to provide end-to-end network transparency with consistent network experience through comprehensive configuration, compliance and policy management.
RMON and sFlow provides advanced monitoring and reporting capabilities for statistics, history, alarms, and events.
Data sheet
- Basic switching RJ-45 Ethernet ports quantity
- 48
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- Colour of product
- Black
- Depth
- 420 mm
- Dimensions (WxDxH)
- 440 x 420 x 43.6 mm
- Electromagnetic compatibility
- FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003 Class A; ANSI C63.4 2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR22 Class A; EN 61000-3-2; EN 61000-3-3; EN 61000-4-2; EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN
- Flash memory
- 96 MB
- Heat dissipation
- 198 BTU/h
- Height
- 990mm
- I/O ports
- 48 RJ-45 autosensing 10/100 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3at PoE+); Duplex: half or full; 4 SFP 1000 Mbps ports; 2 dual-personality 1000 Mbps ports (IEEE 802.3ab Type 1000BASE-T); 1 RJ-45 serial console port;
- Internal memory
- ≈ 5,000 Cat 8 with plots; ≈ 12,000 Cat 6A with plots
- Latency
- 100 Mb Latency: < 6 µs; 1000 Mb Latency: < 5 µs
- MAC address table
- 96000 entries
- Management platform
- IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager
- Memory type
- SDRAM
- Mounting
- Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)
- Operating relative humidity range
- 5 to 95%
- Operating temperature range (T-T)
- 0 - 50 °C
- Power consumption (typical)
- 440W
- Safety
- UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60950-1/A11; FDA 21 CFR Subchapter J; ROHS Compliance
- Size
- 43.99 cm (17.32")
- Source data-sheet
- Icecat.biz
- Storage temperature range (T-T)
- -40 - 70 °C
- Switch layer
- L7
- Switching capacity
- 993.6 Gbps
- Throughput
- VHT20, VHT40, VHT80
- Weight
- 10000 g
- Width
- 993 mm
Specific References
- EAN13
- 0888182025871
